首頁 > 供應產品 > R&S 羅德與斯瓦茨數位式示波器示波器價格 R&S 羅德與斯瓦茨 RTM4000

R&S 羅德與斯瓦茨數位式示波器示波器價格 R&S 羅德與斯瓦茨 RTM4000

產品：	瀏覽次數：422R&S 羅德與斯瓦茨數位式示波器示波器價格 R&S 羅德與斯瓦茨 RTM4000
單價：	14000.00元/臺
最小起訂量：	1 臺
供貨總量：
發貨期限：	自買家付款之日起天內發貨
有效期至：	長期有效
最后更新：	2024-01-08 09:33

詳細信息

型號 :	RTM4000	類型 :	數字示波器
通道數 :	4	帶寬 :	100MHz至 1GHz
采樣率 :	5 Gsample/s	記錄長度 :	80 Msample
重量 :	4	加工定制 :	否

產品特點

Z大帶寬：200MHz至 1GHz

Z大採樣率：5 Gsample/s

Z大記憶深度：1 Gsample

Z小RMS noise floor 80uV

10 bits垂直分辨率

顯示屏：10.1英寸電容式觸摸屏

內建USB+LAN標準介面

Specifications
Item		RTA4004	RTA4004 with -B243 option	RTA4004 with -B245 option	RTA4004 with -B2410 option
Bandwidth (–3 dB)	50Ω input	200 MHz	350 MHz	500 MHz	1 GHz
	1 MΩ input	200 MHz	350 MHz	500 MHz	500 MHz
Vertical system
Vertical resolution		10 bit, up to 16 bit with high resolution decimation
DC gain accuracy		±1 %... (input sensitivity > 5 mV/div)±1.5 % (input sensitivity ≦ 5 mV/div to ≧ 1 mV/div )±2.5 % (input sensitivity < 1 mV/div)
Input sensitivity	50Ω input	0.5 mV/div to 1 V/div
	1 MΩ input	0.5 mV/div to 10 V/div
RMS noise floor (meas.)	50Ω input (0.5 mV/div~1 V/div)	0.05mV~22.7mV	0.07mV~22.8mV	0.08mV~25.1mV	0.11mV~31.4mV
	1 MΩ input (0.5 mV/div~10 V/div)	0.09mV~226mV	0.1mV~250mV	0.13mV~298mV	0.13mV~298mV
Maximum input voltage	50Ω input	5 V (RMS), max. 30 V (Vp)
	1 MΩ input	300 V (RMS), 400 V (Vp), derates at 20 dB/decade to 5 V (RMS) above 250 kHz
Rise time		< 1.75 ns	< 1 ns	< 700 ps	< 350 ps
Horizontal system
Timebase	range	0.5 ns/div and 500 s/div
	accuracy	±1 ppm (during calibration interval)
Trigger system
Trigger	level	±5 div from center of screen
	modes	auto, normal, single, n single
	Hold-off range	inactive or 51.2 ns to 13.7 s
	types	edge, width, video, pattern, runt, rise time, fall time, serial bus, line, timeout
Edge trigger A	trigger events	rising edge, falling edge, both edges
	coupling	DC, AC (attenuates < 10 Hz (meas.)), LF reject (attenuates < 10 kHz (meas.))
Edge trigger A and B	trigger events	rising edge, falling edge, both edges
Width trigger	events	pulse width is smaller, greater, equal, unequal, inside interval, outside interval
	pulse width	3.2 ns ~ 6.8 s
Timeout trigger	events	greater than timeout
	timeout range	3.2 ns ~ 6.8 s
Video trigger	events	selectable line, all lines, even frame, odd frame, all frames
	supported standards	PAL, NTSC, SECAM, PAL-M, SDTV 576i, HDTV 720p, HDTV 1080i, HDTV 1080p
Pattern trigger Runt trigger Rise time, fall time Serial bus trigger External trigger input		reference to Specifications Data Sheet

Digital channel inputs		D15 to D8, D7 to D0 (RTA-B1 option)

Menu languages		Traditional Chinese,Simplified Chinese ,English,German,French, Spanish,Italian, Portuguese,Czech,Polish,Russian,Korean,Japanese
Interface		USB 1 port, type B plug, version 2.0 LAN 1 port, 1 Gbit

Choose additional probes
Single-ended passive probes	RT-ZP05S	500 MHz, 10 MΩ, 10:1, 300 V, 10 pF, 5 mm
	RT-ZP10	500 MHz, 10 MΩ, 10:1, 400 V, 9.5 pF, 2.5 mm
	RT-ZP1X	38 MHz, 1 MΩ, 1:1, 55 V, 39 pF, 2.5 mm
Active broadband probes: single-ended	RT-ZS10L	1.0 GHz, 10:1, 1 MΩ, BNC interface
	RT-ZS10E	1.0 GHz, active, 1 MΩ, R&S interface
	RT-ZS10	1.0 GHz, active, 1 MΩ, R&S ProbeMeter, micro button, R&S probe interface
	RT-ZS20	1.5 GHz, active, 1 MΩ, R&S ProbeMeter, micro button, R&S probe interface
Active broadband probes: differential	RT-ZD10	1.0 GHz, active, differential, 1 MΩ, R&S ProbeMeter, micro button, incl. 10:1 external attenuator, 1 MΩ, 70 V DC, 46 V AC (peak), R&S probe interface
	RT-ZD20	1.5 GHz, active, differential, 1 MΩ, R&S ProbeMeter, micro button, R&S probe interface
	RT-ZPR20 Power rail probe	2.0 GHz, 1:1, 50 kΩ, ±0.85 V, ±60 V offset, R&S probe interface
High voltage single-ended passive probes	RT-ZH03	250 MHz, 100:1, 100 MΩ, 850 V, 6.5 pF
	RT-ZH10	400 MHz, 100:1, 50 MΩ, 1000 V, 7.5 pF
	RT-ZH11	400 MHz, 1000:1, 50 MΩ, 1000 V, 7.5 pF
High voltage probes: differential	RT-ZD002	25 MHz, 20:1/200:1, 4 MΩ, 1.4 kV (CAT III), BNC interface
	RT-ZD003	25 MHz, 10:1/100:14 MΩ, 700 V (CAT II), BNC interface
	RT-ZD01	100 MHz, 8 MΩ, 1 kV (RMS) (CAT III), BNC interface
	RT-ZD02	200 MHz, 10:1, ±20 V, BNC interface
	RT-ZD08	800 MHz, 10:1, 200 kΩ, ±15 V, BNC interface
	RT-ZHD07	200 MHz, 250:1/25:1, 5 MΩ, 750 V (peak), 300 V CAT III, R&S probe interface
	RT-ZHD15	100 MHz, 500:1/50:1, 10 MΩ, 1500 V (peak), 1000 V CAT III, R&S probe interface
	RT-ZHD16	200 MHz, 500:1/50:1, 10 MΩ, 1500 V (peak), 1000 V CAT III, R&S probe interface
	RT-ZHD60	100 MHz, 1000:1/100:1, 40 MΩ, 6000 V (peak), 1000 V CAT III, R&S probe interface
Current probes	RT-ZC02	20 kHz, AC/DC, 0.01 V/A and 0.001 V/A, ±200 A and ±2000 A, BNC interface
	RT-ZC03	100 kHz, AC/DC, 0.1 V/A, 30 A, BNC interface
	RT-ZC05B	2 MHz, AC/DC, 0.01 V/A, 500 A (RMS), R&S probe interface
	RT-ZC10	10 MHz, AC/DC, 0.01 V/A, 150 A (RMS), BNC interface
	RT-ZC10B	10 MHz, AC/DC, 0.01 V/A, 150 A (RMS), R&S probe interface
	RT-ZC15B	50 MHz, AC/DC, 0.1 V/A, 30 A (RMS), R&S probe interface
	RT-ZC20	100 MHz, AC/DC, 0.1 V/A, 30 A (RMS), BNC interface
	RT-ZC20B	100 MHz, AC/DC, 0.1 V/A, 30 A (RMS), R&S probe interface
	RT-ZC30	120 MHz, AC/DC, 1 V/A, 5 A (RMS), BNC interface
EMC near-field probes	HZ-15	Probe set for E and H near-field measurements, 30 MHz to 3 GHz
Logic probes	RT-ZL04	400 MHz logic probe, 8 channels

Option
Hardware	RTA-B1	Mixed signal option, additional 16 logic channels
	RTA-B6	Waveform generator and 4-bit pattern generator
Software	RTA-K1	I2C triggering and decoding and SPI triggering and decoding
	RTA-K2	UART/RS-232/RS-422/RS-485 triggering and decoding
	RTA-K3	CAN triggering and decoding and LIN triggering and decoding
	RTA-K5	Audio (I2S, LJ, RJ, TDM) triggering and decoding
	RTA-K6	MIL-STD-1553 triggering and decoding
	RTA-K7	ARINC 429 triggering and decoding
	RTA-K18	Spectrum analysis and spectrogram
	RTA-K31	Power analysis
	RTA-K36	Frequency response analysis – Bode plot
